DevOps Metrics – Defining Measurements for Achieving High Performance Software Development

The critical framework for defining and achieving high performance DevOps are process metrics.

The principle function of a DevOps Centre of Excellence and the critical framework for defining and achieving high performance are process metrics.

Establishing the right ones will enable development teams to define and measure what matters, providing a control loop for ensuring their transformation and new working processes deliver the results they want.

To determine the business case for Continuous Deployment practices the key dynamic is ‘Business Value Throughput’. Ie. not just speeding up the production of deployed code but of software that adds quantifiable value to the organisation.

DevOps Metrics

In his blog, Matt Dickens also explores the same area, providing a very helpful guide to ‘Choosing the Right Metrics for DevOps Adoption’.

Matt starts with the key point that the transformation is an ongoing, long term process of transformation, and like always the success factor is having a clear end goal in mind and then breaking it down into a series of ‘bite size chunk’ steps to progress along that journey.

His article is very helpful because he provides an initial list for suggestions of what these steps might be for different organisations at different stages of their adoption, and then maps each step to the most effective tools and practices improvements to make to progress against that specific metric, such as:

  • Deployment time
  • Change failure rate
  • Release cadence
  • Lead time
  • Recovery time

Flow Metrics

In the feature video Mik Kersten, Founder and CEO of Tasktop, describes his journey and evolution as a software developer that led him to understand what is required to achieve high performance software development teams.

He has encoded that learning into the principle of Value Stream Networks that can be implemented and managed through Flow Metrics.

There are four Flow Metrics that measure how value flows through a product’s value stream, calculated on four Flow Items – units of work that matter to a business: features, defects, debt, and risk. Any task or effort a software delivery organization undertakes can be categorized as one of these core Flow Items.

  • Flow Velocity gauges whether value delivery is accelerating also referred to as throughput.
  • Flow Time measures the time it takes for Flow Items to go from ‘work start’ to ‘work complete’, including both active and wait times.
  • Flow Efficiency is the ratio of active time vs. wait time out of the total Flow Time and
  • Flow Load monitors the number of Flow Items currently in progress (active or waiting) within a particular value stream.

Tasktop describes the central challenge and the need for a new, better approach for capturing and reporting on productivity:

“While IT frequently collects and presents an abundance of technical metrics regularly, quite often they measure the process and not the outcome. Also referred to as ‘proxy metrics’, these metrics include things like story-points delivered, commits per project, test case coverage, build success rate, release duration, and deployments per day.

Good measures of a process are helpful to monitor the performance of a specific activity, but they usually don’t help IT and business leaders optimise the system’s performance as a whole, from customer request to delivery. Furthermore, optimising something that is not the system’s bottleneck is actually inefficient and counter-productive.”

Project to Product

Mik has also documented his insights into a book Project to Product, and in this talk he summarizes it by showing how a product operating model can provide the critical glue between the hierarchical and finance-oriented structures of the business and the agility enabled by delivery teams adopting SAFe.

As the title suggests this is centred around a shift from a waterfall, project budgeting approach to one of ‘Lean Budgets‘.

Lean and value stream thinking originated in manufacturing but have become highly popularized in software delivery by the DevOps movement: With developers releasing code changes more frequently thanks to Agile, DevOps set its sights on getting those code changes running in production faster.

Flow Metrics: Flow time, Flow Velocity, Flow Efficiency

In this webinar Dominica DeGrandis explains Flow Metrics in detail and how to implement these key metrics at an organization and how to enhance the impact of software products.

From 2.08 she sets the scene defining that that flow metrics are tied to business value and are based on outcomes. Flow metrics provide a feedback loop to improve decisions.

At 4:36 Dominica explains the metric, ‘Flow Time’. Flow Time is the duration from when work enters the value stream to its completion. This metric is helpful in answering questions like ‘What’s the probability of completing work in X days?

This metric helps in identifying when the time to value is getting longer, and is the measure of time taken for the items to process from ‘start’ to ‘complete’ state. This would include both active and wait times.

At 16:32 she moves on to discussing the next important metric, which is the ‘Flow Velocity’.

Flow Velocity can be defined as the number of items completed during a given duration of time. This metric is easy to calculate and provides data to the software development teams to view the delivery rates, gauging if the value delivery is progressing in an accelerated manner. This metric is commonly referred to as throughput.

At 19:12 Dominica states that there are two important factors that need to be considered while choosing the batch size. Batch size is often decided based on the transaction cost and holding cost. Reducing the batch size of work helps in reducing the WIP (Work in progress) limit and improves the flow.

The optimal batch size primarily depends on holding cost including the cost for delayed feedback, inventory decay, and delayed value delivery). Software development teams must always focus on reducing the transaction costs of any batch.

At 20:51 Dominica explains the ‘Flow Efficiency’ metric, the percentage of time where work is in an active state and is a metric to expose wait time. Flow efficiency metrics can easily help in identifying when waste is decreasing or increasing in a process. In other work, these metrics can be defined as the ratio of active time vs wait time of the overall flow time.

At 30:22 she defines the metric ‘Flow Load’, a metric to measure the balance between demand and capacity. Flow Load is responsible for monitoring the over-utilized and under-utilized value streams, where often the over-utilization and the under-utilization of value streams can lead to reduced productivity. This metric measures the number of Flow Items that are currently in the active or waiting state within a specific value stream.

At 31:32 she emphasizes that WIP (Work in progress) is a leading indicator, for example a high WIP means that the other items are waiting in the queue for a longer time. The important factor which affects queue size is capacity utilization, the metric to calculate the rate at which the outputs are being achieved.

Queueing Theory

From 33:00 Dominica discusses the ‘Queueing Theory’, which enables quantifying the relationship between wait times and capacity utilization. As the capacity utilization approaches 100%, wait time increases exponentially.

Software development teams need to consider managing work by queues if the desired goal is speed. At 35:47, she mentions that the amount of WIP (Work in progress) is the primary factor of speed. If there is a requirement to achieve maximum business value, the proportion of work items in a value stream needs to be adjusted. Often a decision to do one thing is a decision to delay something else.

At 43:20 she illustrates a sample value stream dashboard displaying all the flow metrics. The dashboard would comprise prominent flow metrics like Flow Efficiency, Flow Time, Flow Load, Flow Velocity, and Flow Distribution. The dashboards can also have the business value, business cost, business happiness, and business quality index.

At 46:35 Dominica talks about the metric to gauge happiness, a metric that answers questions like ‘How likely are you to recommend working for this company to a friend?

If you are interested in visualizing and optimizing the business value of your software delivery, measuring business outcomes is a must, and Flow Metrics provide a framework for achieving this.
